Valve Type | Class Rating | Size Range | Shell Material As Per Specification |
Globe Valve | 150# | 2" to 24" | ASTM A216 Gr. WCB ASTM A217 Gr. WC1 ASTM A217 Gr. WC6 ASTM A217 Gr. WC9 ASTM A217 Gr. C5 ASTM A217 Gr. C12 ASTM A351 Gr. F8 ASTM A351 Gr. F3 ASTM A351 Gr. F8M ASTM A351 Gr. CF3M ASTM A351 Gr. CN7M ASTM A351 Gr. CF8C ASTM A351 Gr. CD4Mcu ASTM A351 Gr. CK3MCuN ASTM A352 Gr. LCA ASTM A352 Gr. LCB ASTM A352 Gr. LCC ASTM A494 Gr. CW6MC ASTM A494 Gr. CW2M ASTM A494 Gr. CW2M ASTM A494 Gr. CY40 ASTM A494 Gr. CU5MCuC ASTM A995 Gr. 1A ASTM A995 Gr. 4A ASTM A995 Gr. 5A ASTM A995 Gr. 6A NACE malt. Grade to NACE MR0175/NACE MR |
Globe Valve | 300# | 2" to 24" | |
Globe Valve | 600# | 2" to 12" | |
Globe Valve | 800# | 1/2" to 2" | |
Globe - Pressure Seal Valve | 900# | 1/2" to 12" | |
Globe - Pressure Seal Valve | 1500# | 1/2" to 12" | |
Globe - Pressure Seal Valve | 2500# | 2" to 4" | |
Globe - Cryogenic Valve | 150# | 2" to 16" | |
Globe - Cryogenic Valve | 300# | 2" to 16" | |
Globe - Cryogenic Valve | 600# | 2" to 16" | |
Note:
|
HANDWHEEL
2” – 10” - Class 150, 300
2” – 6 ” - Class 600
2” – 4 ” - Class 900, 1500
GEAR OPERATOR
12” & Above - Class 150 & 300
8” & Above - Class 600
12” & Above - Class 900 & 1500
STRUCTURE | End Connection | Flanged End Raised Face, Butt Weld End, RTJ,. ETC | |
Operation | Hand wheel, Gear Operator, Electrical Actuator, Pneumatic, Hydraulic | ||
MATERIAL | Shell | WCB, WC1, WC6, WC9, LCB, LCC, LC3, C5, C12, CF8, CF8M, CF3, CF3M, CF8C, CN7M, CD4MCu, Hastelloy, Inconel, Duplex Stainless Steel |
|
Trim | 13% Cr Steel, 304 , 304L, 316, 316L, 321, 347, F51, Monel |
