PLUG VALVES MANUFACTURERS IN INDIA
Hani Enterprises Plug Valve available in sizes ranging from 1/2" – 72" is designed specifically for wastewater applications. The round port design available on sizes 1/2" – 12", offers the least resistance to slurry, sludge, and fluid flow resulting in less erosion, longer service life, and reduced pumping costs. The large round port design can pass larger solids reducing plugging problems. Round port valves offer the best flow characteristics compared to alternative port openings, resulting in less pressure drop across the valve. Pressure classes on 12" and smaller is 175 psi, pressure classes on 14" and larger is 150 psi, higher pressure on request.
Flow Control & Isolation Solved
Eccentric Plug Valves can be used for a wide range of flow control and isolation applications including clean and dirty water, sewage, sludge and slurries, air and other services. Available with EPDM, Nitrile, Neoprene and Fluroelastomer Rubber encapsulated plugs. The Eccentric Plug Valve can be used to isolate and regulate any of these services bi-directionally.
Quality Construction
Manufactured in cast iron, using high pressure moulding techniques for consistent quality and precision, the Eccentric Plug Valve also incorporates a nickel weld deposited seat for corrosion and erosion resistance, specially profiled for low torque and extended seat life. At DN65 epoxy seat only. The Eccentric Plug Valve is trunnion supported and fully encapsulated in an elastomeric polymer. The valve body is fully internally and externally Epoxy coated as standard. A rubber lined option is also available. Offering a high flow capacity with a round port design in sizes up to DN300 (larger sizes have rectangular ports), the Eccentric Plug Valve design ensures that the ductile iron plug rotates away from the seat as soon as movement begins, avoiding scuffing and thereby enhancing life expectancy.
Plug valves are valves with cylindrical or conically tapered "plugs" which can be rotated inside the valve body to control flow through the valve. The plugs in plug valves have one or more hollow passageways going sideways through the plug, so that fluid can flow through the plug when the valve is open.
- Size: ½” up to 36“ (DN15 up to Dn900)
- Pressure Rating: ASME 150# to 2500#
- Materials: Carbon Steels, Low Temperature Carbon Steel, Martensitic Steels, Austenitic Stainless Steel, Duplex Stainless Steels, Super Duplex Stainless Steels, Nickel Alloys, Nickel Aluminum Bronze, Hastelloy, Inconnel, Titanium Alloy & Carbon Steel with Internal CorrosionResistant Alloy (CRA) Overlay
- Design Standard: API6D, API 599, BS 5353, MESC SPE 77/107
- Pressure / Temperature Rating: ASME B 16.34
- Test (Inspection) Standard: API 598, API 6D, MESC 77/107, ISO 5208
- Construction Details: Inverted Plug Pressure Balanced /Lubricated
- End Connection: Screwed, Socket Weld, Flanged, Hub End, Butt-Weld
- Operator / Actuator: Lever, Gear, Actuator (Pneumatic, Hydraulic, Electro-Hydraulic and Electric Motorised)
Plug Valves are available in three different types versions
• Full Bore
• Regular Bore
• Extended Stem Valves
Sleeved Plug Valve
Rating：150~900LB (PN16~PN160) Body Materials：Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel End Connection： RF |
Lubricated Plug Valve
 Size：2~24"(DN50~DN600) Rating：150~900LB (PN16~PN160) Body Materials：Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel End Connection： RF |
Steam Jacket Plug Valve
 Size：2~24"(DN50~DN600) Rating：150~900LB (PN16~PN160) Body Materials：Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel End Connection： RF |
Plug Valve SS904L Material 6 Inch 150 LB PTFE Sleeve
Plug ValveSize:6inch
Pressure Rating: Class 150LB
Material: SS904L
Sleeve:PTFE
Inverted Pressure Balance Lubricated Plug Valve 6 inch 600 LB A216 WCB API 599
Key Specifications / Features
Details
Body: ASTM A216 WCB
Plug: Carbon Steel or Stainless Steel
Seat:A105
Features
It has the structure of flip-chip balanceable pressure and ligh on/off operation.
An oil groove is set between valve body and seal surface,which may infuse the seal grease to increase the seal capablility.
It is applied to the industries such as petroleum,chemical,pharmacy,electricity,etc
Standards
Design and Manufacture: API 599, API 6D
Face to Face(end to end): ASME B16.10,DIN3202 F1
Flanged Ends: ASME B16.5,ASME B16.5, ASME B16.47,DIN2543-2549.
Test and Inspection: API 598, API 6D, DIN3230
Pressure-Temperature Ratings:ASME B16.34
Stainless Steel Plug Valve 6 inch 150 LB SS904L PTFE Sleeve
Key Specifications / Features
Details
Size:6 inch
Pressure:150LB
Body: SS904L
Plug:Stainless Steel
Sleeve:PTFE
Seat:PTFE
Features
Bolted cover,plug 90 degree around.
The sealing is realized by the face around the sleeve.
It has unique 360 degree metal edge for protection and fixing of the sleeve.
Standards
Design and Manufacture: API 599, API 6D,ASME B16.34
Face to Face: ASME B16.10,EN 558-1
Flanged Ends: ASME B16.5,EN1092-1
Test and Inspection: API 598, API 6D,DIN3230
Pressure-Temperature Ratings:ASME B16.34
Sleeved Plug Valve 4 inch 150LB PTFE Sleeve API599
Key Specifications / Features
Details
Size:4 inch
Pressure:150LB
Body: A351 CF8M
Plug:Stainless Steel
Sleeve:PTFE
Features
Bolted cover,plug 90 degree around.
The sealing is realized by the face around the sleeve.
It has unique 360 degree metal edge for protection and fixing of the sleeve.
Standards
Design and Manufacture: API 599, API 6D,ASME B16.34
Face to Face: ASME B16.10,EN 558-1
Flanged Ends: ASME B16.5,EN1092-1
Test and Inspection: API 598, API 6D,DIN3230
Pressure-Temperature Ratings:ASME B16.34
